Electroplated Diamond & CBN Grinding Wheels
Ideal for carbide tools grinding, forming, ferrite core grinding & re-sharpening.
 |
 |
 |
 |
 |
 |
Indication of diamond & CBN grinding wheels
| SD Abrasives |
150 Grit Size |
N Grade |
75 Concentration |
R Bond |
3.0 Rim thickness |
|
| D : Natural diamond | #60 | J | Soft | 25 | RB: Resin bond | 1.0mm |
| SD : Synthetic diamond | #80 | L |  |
50 | MB: Metal bond | 1.5mm |
| SDC : Synthetic metal | #100 | N | 75 | P: Electroplated | 2.0mm | |
| coating diamond | #150 | P | 100 | VB: Vitrified Bond | 3.0mm | |
| B : Cubic boron nitride | #200 | R | Hard | 125 | 5.0mm | |
| (CBN) | #270 | 150 | 10.0mm | |||
| BC : CBN with metal | #325 | |
||||
| coating | #400 | |||||
| #600 | ||||||
|
||||||
Method of Choosing Diamond & CBN Grinding Wheels:
- Tungsten carbide, presintered carbide metal tools & construction units.
- Oxide ceramic materials.
- Ferrite, ceramic magnetic materials.
- Refractory products.
- Stones, gem & semi-precious stones, shell.
- Glass, porcelain, quartz.
- Graphite, carbon.
- Tiles, asbestos, asphalt, concrete.
- Plastics, F.R.P.
- Wear resistant coatings.
- High alloy steels.
- High speed tool steels.
- Hot & cold working steels.
- Tempering steels, Spring steels.
- Ball bearing steels.
- Cast iron.
* Special size can be customized on request.
